Welded Steel 30kn - 100kN Reel Carrier Trailer For Cable Drum Hauling Reel Max Diameter 2400~3600mm

Name: Welded Steel 30kn 100kN Reel Carrier Trailer For Cable Drum Hauling Reel Max Diameter 24003600mm
Brand: Boyu
Price: 1 USD

Place of Origin : China

Brand Name : Boyu

Certification : ISO9001

Model Number : TYDLG

MOQ : 10 set

Price : Negotiable

Packaging Details : Carton

Delivery Time : 30 days

Payment Terms : TT/LC

Supply Ability : 100 sets/month

OEM : Available

Material : Welded steel

Brand : Boyu

Max capacity : 30-100kN

Reel diameter : 2400~3600mm

Axel diameter : 80-150mm

Contact Now

30kn - 100kN Transmission Line Stringing Tools , Reel Carrier Trailer For Cable Drum Hauling

Quick details:

1.Transimission line stringing tools

2. Reel Carrier Trailer

3.Material: Welded steel
4.Max capacity:30-100kN
5.Reel diameter:2400~3600mm
6.Axel diameter:80-150mm

7.Boyu Brand

Description:

The reel carrier is made of welded steel with protective coating. Two hydraulic jacks are used to lift the reel. Special models with different characteristics can be designed on demand.

Specification:

Model	Max Capacity (kN)	Reel Dimensions(mm)			Overall dimensions(mm)	Weight (kg)
Model	Max Capacity (kN)	Diameter	Width	Axel diameter	Overall dimensions(mm)	Weight (kg)
DLG-3T	30	2400	1250	80	3800×2300×2200	900
DLG-5T	50	2800	1450	100	4000×2600×2500	1500
DLG-8T	80	3400	1800	120	4300×3200×2700	2300
DLG-10T	100	3600	2000	150	4600×3800×2900	3100

Remarks: the trailer can be transported by container after disassembly.

Please contact us if you have any requirement, and we can make products with special specification as your requirements.

More pictures of the Reel Carrier Trailer :

Company instruction:

Jiangsu Province Yixing Boyu Electric Power Machinery Company is located in west side of the beautiful and fertile Taihu Lake.
Our company is high-tech enterprise of Jiangsu province having six patents, including two invention patents. Our company has a total area of 42800 square meters, having formed four series products:
1: Transmission line stringing equipment and accessories and tools.
2: Nonmetallic galvanized the production equipment (Achieved high-tech products)
3: Numerical control machine
4: Low voltage no power-arc furnace compensation system
